1/2-Inch Heliax Superflexible Foam Coaxial Cable – Corrugated Copper, Black PE Jacket (FSJ4-50B)

Description

[pdf] [/pdf]

FSJ4-50B HELIAX Superflexible Foam Coaxial Cable, 1/2 in, Corrugated Copper Black PE Jacket

Applications:

All HELIAX coaxial cables are jacketed for direct burial or for corrosive environmental conditions. Standard jacketing material is weather-resistant polyethylene suitable for use
in extreme climates.

Also Known As:

FSJ4-50B Coaxial Cable, HELIAX Superflexible Foam Coaxial Cable, Coaxial Cable, Corrugated Copper Black PE Jacket.

Product Classification:

Product Type: Coaxial wireless cable
Product Brand: HELIAX | SureFlex
Product Series: FSJ4-50B
Ordering Note: ANDREW standard product (Global)

General Specifications:

Product Number: 520093902/00    |   SZ520093902/00
Flexibility: Superflexible
Jacket Color: Black
Performance Note: Attenuation values typical, guaranteed within 5%

Dimensions:

Diameter Over Dielectric: 8.89 mm   |   0.35 in
Diameter Over Jacket: 13.462 mm   |   0.53 in
Inner Conductor OD: 3.556 mm   |   0.14 in
Outer Conductor OD: 12.192 mm   |   0.48 in
Nominal Size: 1/2 in

Electrical Specifications:

Cable Impedance: 50 ohm ±1 ohm
Capacitance: 82.7 pF/m   |   25.207 pF/ft
dc Resistance, Inner Conductor: 2.69 ohms/km   |   0.82 ohms/kft
dc Resistance, Outer Conductor: 5.12 ohms/km   |   1.561 ohms/kft
dc Test Voltage: 2500 V
Inductance: 0.207 µH/m   |   0.063 µH/ft
Insulation Resistance: 100000 MOhms-km
Jacket Spark Test Voltage (rms): 5000 V

FSJ4-50B:

Operating Frequency Band: 1 – 10200 MHz
Peak Power: 22.5 kW
Velocity: 81 %

Material Specifications:

Dielectric Material: Foam PE
Jacket Material: PE
Inner Conductor Material: Copper-clad aluminum wire
Outer Conductor Material: Corrugated copper

Mechanical Specifications:

Minimum Bend Radius, multiple Bends: 31.75 mm   |   1.25 in
Minimum Bend Radius, single Bend: 31.75 mm   |   1.25 in
Number of Bends, minimum: 20
Number of Bends, typical: 50
Tensile Strength: 79 kg   |   174.165 lb
Bending Moment: 2.7 N-m   |   23.897 in lb
Flat Plate Crush Strength: 2 kg/mm   |   111.995 lb/in

Environmental Specifications:

Installation temperature: -40 °C to +60 °C (-40 °F to +140 °F)
Operating Temperature: -55 °C to +85 °C (-67 °F to +185 °F)
Storage Temperature: -70 °C to +85 °C (-94 °F to +185 °F)
Attenuation, Ambient Temperature: 68 °F   |   20 °C
Average Power, Ambient Temperature: 104 °F   |   40 °C
Average Power, Inner Conductor Temperature: 212 °F   |   100 °C

Packaging and Weights:

Cable weight: 0.21 kg/m   |   0.141 lb/ft

Regulatory Compliance/Certifications:

Agency                       Classification
CENELEC                    EN 50575 compliant, Declaration of Performance (DoP) available
CHINA-ROHS             Below maximum concentration value
ISO 9001:2015           Designed, manufactured and/or distributed under this quality management system
REACH-SVHC            Compliant as per SVHC revision on
ROHS                        Compliant
UK-ROHS                  Compliant

Compatible with Manufacturer
Andrew:	FSJ4-50B
